★Residential · Service

Video Walls · Kansas City.

Where you sit sets the pitch. Everything after that is construction. IntegrateIT designs and installs LED and direct-view LED video walls across the Kansas City metro from Overland Park: theater and great-room feature walls, executive office walls, outdoor-rated patio LED and retractable systems, sized to the room and run from Control4 or Crestron. We size the wall from the seats, then solve the structure, the power, the heat and the service access before anything is ordered. Phone: (913) 804-7575 or office@integrateit.tech.

Below: how pitch and viewing distance decide the spec, the honest comparison against a projector and against a single large display, why a video wall is a construction scope, what a Kansas City basement or an old plaster wall changes, and what happens in year six when a tile fails.

Pitch is set by the seats, not by the spec sheet

Pixel pitch is the spacing between the LEDs on a tile, and it is the one number that drives cost per square foot more than any other. It also has a hard physical meaning: below a certain viewing distance the image stops resolving as a picture and starts resolving as individual points of light. Finer pitch buys you the right to sit closer. That is the whole of it.

Which is why the first thing we do is measure where people will actually sit — not where the furniture is today, but where the seating will be once the room is finished, including the closest regular seat rather than the one somebody perches on twice a year. Pitch is then chosen for that distance and no finer. Buying a very fine pitch for a great room whose sofas sit well back is spending real money on something no one in the room can perceive, and that money does more good in the processing, the calibration and the frame behind the tiles. The opposite mistake is worse and less recoverable: a coarse pitch in a room where people sit close, which looks like a scoreboard and cannot be fixed with settings.

Against a projector, and against a big display

We install all three, so this comparison costs us nothing to make honestly. A projector and screen give the most picture for the money and, in a properly dark dedicated room, the most cinematic image — a JVC projector on a Stewart Filmscreen surface in a treated theater is still the reference answer, and it is what we specify on plenty of home theater projects. Its weakness is ambient light. A great room with west windows will defeat a projector at four in the afternoon regardless of the lumens claimed on the box.

A single large display is the simplest answer, needs no special structure, arrives in one piece and costs a fraction of a wall. Its limit is size: past the largest panel a manufacturer offers, there is nowhere to go. And the wall is the answer to exactly that — a picture bigger than any display, bright enough to hold its own in daylight, in whatever aspect ratio the architecture wants rather than the one the industry ships. It costs the most, it asks the most of the room, and it is genuinely spectacular in the right room. What it is not is a replacement for a projector in a dark theater, and we will say so rather than sell up.

There is a fourth option worth naming, because people ask for it by description rather than by name: a television that folds, rises or lifts out of sight when the room is a room again. That is C SEED, and it answers a different question from a fixed wall — hide the picture, rather than make it as large as possible. The indoor models are a floor-structure conversation and the outdoor ones are a site-work project, so they get decided during design rather than after the patio is poured.

A video wall is construction wearing a display costume

Once the pitch and the size are settled, the remaining decisions belong to the building. This is the part that is missing from most quotes.

The line we build these from is Just Video Walls, whose page names the Autograph and Lunar Walls product families and explains pixel pitch, brightness, serviceability, power and heat, mounting depth and the video path in plain words. Where the canvas belongs to a building rather than to a room — a lobby, a boardroom, a control room — the commercial platforms are Media Resources. Where the wall also has to behave like a television — a residence, a club, a hospitality bar — the direct-view lines we carry and install are LG MAGNIT and Samsung The Wall, each with its own page. And where the wall has to run continuously and be serviced for years — a control room, a command centre, a boardroom nobody is allowed to take offline — we also carry and install Barco, whose TruePix and NT tiles are built around failover, eye comfort over a long shift and module supply measured in years rather than months.

• Structure. The load is continuous across the whole wall, not concentrated on two brackets. We verify framing or masonry and add blocking or a steel subframe where it is needed. This is decided before drywall if we are lucky enough to be there.
• Flatness. Tiles butt edge to edge with no bezel to hide behind, so a bow of a few millimeters becomes a visible seam across the picture. We build an adjustable frame and shim it flat rather than trusting the wall.
• Power. A wall of that size wants its own circuits, coordinated with the electrician, sized for inrush rather than for average draw, and ideally on conditioned power alongside the rest of the rack.
• Heat. The wall puts real heat into the room continuously. In a closed basement theater that changes the load on the mechanical system, and it is much cheaper to raise with the HVAC contractor at design than to solve with a portable unit later.
• Service depth. Front-serviceable tiles pull from the room side and need almost no depth behind. Rear-serviceable designs cost less and need a service corridor, which a wall built tight against a foundation cannot have. This decision is permanent.
• Acoustics. A large, hard, flat surface at the front of a room changes how the room sounds, which matters in a theater. The treatment argument is on our acoustic treatment page, and it should be settled at the same time as the wall, not after.

Kansas City basements and old plaster

Many of the residential walls we are asked about here go in finished lower levels, because that is where the metro puts its big rooms. Those rooms carry three constraints worth knowing early. Ceiling height is usually the real size limit — once the soffits, the duct chase and the beam are accounted for, the wall a room can take is frequently smaller than the wall someone had in mind, and it is better to find that out with a tape measure than with a delivery. Access is the second: crated tiles have to reach the room, and a tight basement stair with a turn at the bottom rules out sizes that a walkout door would have accepted easily. And a lower level is a different thermal and humidity environment, so the room needs conditioned air moving through it rather than being closed up between viewings.

On the other side of the metro, the older houses in Mission Hills, Brookside and the pre-war Prairie Village streets bring the flatness problem to the front. Plaster over lath, masonry chimney breasts and framing that predates modern spacing are almost never flat enough to butt tiles against, and they will not accept a continuous load without help. There the frame is not an upgrade, it is the design: a steel or aluminum subframe carried on verified structure, shimmed true, with the tiles adjusted at every joint. It costs more and it is the difference between a wall and a visible grid of seams.

Calibration, spares and the long view

A wall arrives as a set of tiles that are close to each other and not identical. Calibration is what makes them one picture: uniformity set across the whole array, then color and brightness set for the room it lives in rather than for a showroom. We calibrate after the room is finished, with the actual lighting in place, because a wall tuned against bare drywall is tuned for a room that will not exist by the time you use it.

Then the long view. Spare tiles are bought with the wall, from the same production batch, and stored with the system — a tile sourced years later can read as a patch even when the part number matches. Sources live in a rack somewhere else and reach the wall over structured cable on AVPro Edge or Blustream, so replacing a streamer never involves touching the wall. Control runs through Control4 or Crestron so one press takes the room to a state rather than waking four devices in order. Every install carries a five-year workmanship warranty, the equipment carries its manufacturer warranty, and you have our support for as long as you own the system. If you are weighing a wall against a projector for a theater, our home theater cost guide walks the decisions that actually move the number.
